LONGi Hi-MO X6 Scientist Max solar panel monofacial 620 W

Name: LONGi Hi-MO X6 Scientist Max solar panel monofacial 620 W
Brand: LONGi
SKU: LR7-72HTH-620W-SCIENTIST

The entry bin of the LR7 72-cell Hi-MO X6 Scientist module at 620 W, rated 23.0% module efficiency: the same physical panel as every bin up to 630 W, separated only by measured output.

النوعلوح شمسيالكفاءة23%الوجهوجه واحدالأبعاد2382 x 1134 x 30الخلايا144 (6x24)

القدرة

السعر—

أهم المواصفات

Face	monofacial
Cell count	144 (6x24)
Dimension (mm)	2382 x 1134 x 30
Fire rating	IEC Class C
Front static loading pa	5400
Imp NOCT (A)	11.42
Imp STC (A)	13.94
Isc NOCT (A)	12.06

كل المواصفات36

Face	monofacial
Cell count	144 (6x24)
Dimension (mm)	2382 x 1134 x 30
Fire rating	IEC Class C
Frame	Anodized aluminum alloy frame
Front static loading pa	5400
Glass	Single glass, 3.2mm coated tempered glass
Hailstone test	25mm Hailstone at the speed of 23m/s
Imp NOCT (A)	11.26
Imp STC (A)	13.75
Isc NOCT (A)	11.91
Isc STC (A)	14.74
Junction box	IP68
Max series fuse rating (A)	25
Max system voltage (V)	1500
Module code	LR7-72HTH-605M
Module efficiency (%)	22.4
Nominal operating cell temp (°C)	43-47
Operating temperature (°C)	-40 to 85
Output cable	4mm², +400/-200mm/±1400mm length can be customized
Package dimension (mm)	2382 x 1134 x 30
Package weight (kg)	28.5
Packaging	36pcs per pallet/144pcs per 20'GP/720pcs per 40'HC
Pmax NOCT (W)	452.1
Pmax STC (W)	605
Power tolerance (%)	0-3
Protection class	Class II
Rear static loading pa	2400
Temp coeff isc pct per (°C)	0.05
Temp coeff pmax pct per (°C)	-0.28
Temp coeff voc pct per (°C)	-0.23
Vmp NOCT (V)	40.18
Vmp STC (V)	44.03
Voc NOCT (V)	49.17
Voc STC (V)	52.27
Weight (kg)	28.5

Face	monofacial
Cell count	144 (6x24)
Dimension (mm)	2382 x 1134 x 30
Fire rating	IEC Class C
Frame	Anodized aluminum alloy frame
Front static loading pa	5400
Glass	Single glass, 3.2mm coated tempered glass
Hailstone test	25mm Hailstone at the speed of 23m/s
Imp NOCT (A)	11.31
Imp STC (A)	13.81
Isc NOCT (A)	11.95
Isc STC (A)	14.80
Junction box	IP68
Max series fuse rating (A)	25
Max system voltage (V)	1500
Module code	LR7-72HTH-610M
Module efficiency (%)	22.6
Nominal operating cell temp (°C)	43-47
Operating temperature (°C)	-40 to 85
Output cable	4mm², +400/-200mm/±1400mm length can be customized
Package dimension (mm)	2382 x 1134 x 30
Package weight (kg)	28.5
Packaging	36pcs per pallet/144pcs per 20'GP/720pcs per 40'HC
Pmax NOCT (W)	455.9
Pmax STC (W)	610
Power tolerance (%)	0-3
Protection class	Class II
Rear static loading pa	2400
Temp coeff isc pct per (°C)	0.05
Temp coeff pmax pct per (°C)	-0.28
Temp coeff voc pct per (°C)	-0.23
Vmp NOCT (V)	40.32
Vmp STC (V)	44.18
Voc NOCT (V)	49.22
Voc STC (V)	52.42
Weight (kg)	28.5

Face	monofacial
Cell count	144 (6x24)
Dimension (mm)	2382 x 1134 x 30
Fire rating	IEC Class C
Frame	Anodized aluminum alloy frame
Front static loading pa	5400
Glass	Single glass, 3.2mm coated tempered glass
Hailstone test	25mm Hailstone at the speed of 23m/s
Imp NOCT (A)	11.36
Imp STC (A)	13.88
Isc NOCT (A)	12.01
Isc STC (A)	14.87
Junction box	IP68
Max series fuse rating (A)	25
Max system voltage (V)	1500
Module code	LR7-72HTH-615M
Module efficiency (%)	22.8
Nominal operating cell temp (°C)	43-47
Operating temperature (°C)	-40 to 85
Output cable	4mm², +400/-200mm/±1400mm length can be customized
Package dimension (mm)	2382 x 1134 x 30
Package weight (kg)	28.5
Packaging	36pcs per pallet/144pcs per 20'GP/720pcs per 40'HC
Pmax NOCT (W)	459.6
Pmax STC (W)	615
Power tolerance (%)	0-3
Protection class	Class II
Rear static loading pa	2400
Temp coeff isc pct per (°C)	0.05
Temp coeff pmax pct per (°C)	-0.28
Temp coeff voc pct per (°C)	-0.23
Vmp NOCT (V)	40.46
Vmp STC (V)	44.33
Voc NOCT (V)	49.36
Voc STC (V)	52.57
Weight (kg)	28.5

Face	monofacial
Cell count	144 (6x24)
Dimension (mm)	2382 x 1134 x 30
Fire rating	IEC Class C
Frame	Anodized aluminum alloy frame
Front static loading pa	5400
Glass	Single glass, 3.2mm coated tempered glass
Hailstone test	25mm Hailstone at the speed of 23m/s
Imp NOCT (A)	11.42
Imp STC (A)	13.94
Isc NOCT (A)	12.06
Isc STC (A)	14.93
Junction box	IP68
Max series fuse rating (A)	25
Max system voltage (V)	1500
Module code	LR7-72HTH-620M
Module efficiency (%)	23.0
Nominal operating cell temp (°C)	43-47
Operating temperature (°C)	-40 to 85
Output cable	4mm², +400/-200mm/±1400mm length can be customized
Package dimension (mm)	2382 x 1134 x 30
Package weight (kg)	28.5
Packaging	36pcs per pallet/144pcs per 20'GP/720pcs per 40'HC
Pmax NOCT (W)	463.4
Pmax STC (W)	620
Power tolerance (%)	0-3
Protection class	Class II
Rear static loading pa	2400
Temp coeff isc pct per (°C)	0.05
Temp coeff pmax pct per (°C)	-0.28
Temp coeff voc pct per (°C)	-0.23
Vmp NOCT (V)	40.59
Vmp STC (V)	44.48
Voc NOCT (V)	49.59
Voc STC (V)	52.72
Weight (kg)	28.5

Face	monofacial
Cell count	144 (6x24)
Dimension (mm)	2382 x 1134 x 30
Fire rating	IEC Class C
Frame	Anodized aluminum alloy frame
Front static loading pa	5400
Glass	Single glass, 3.2mm coated tempered glass
Hailstone test	25mm Hailstone at the speed of 23m/s
Imp NOCT (A)	11.47
Imp STC (A)	14.01
Isc NOCT (A)	12.12
Isc STC (A)	15.01
Junction box	IP68
Max series fuse rating (A)	25
Max system voltage (V)	1500
Module code	LR7-72HTH-625M
Module efficiency (%)	23.1
Nominal operating cell temp (°C)	43-47
Operating temperature (°C)	-40 to 85
Output cable	4mm², +400/-200mm/±1400mm length can be customized
Package dimension (mm)	2382 x 1134 x 30
Package weight (kg)	28.5
Packaging	36pcs per pallet/144pcs per 20'GP/720pcs per 40'HC
Pmax NOCT (W)	467.1
Pmax STC (W)	625
Power tolerance (%)	0-3
Protection class	Class II
Rear static loading pa	2400
Temp coeff isc pct per (°C)	0.05
Temp coeff pmax pct per (°C)	-0.28
Temp coeff voc pct per (°C)	-0.23
Vmp NOCT (V)	40.73
Vmp STC (V)	44.63
Voc NOCT (V)	49.64
Voc STC (V)	52.87
Weight (kg)	28.5

Face	monofacial
Cell count	144 (6x24)
Dimension (mm)	2382 x 1134 x 30
Fire rating	IEC Class C
Frame	Anodized aluminum alloy frame
Front static loading pa	5400
Glass	Single glass, 3.2mm coated tempered glass
Hailstone test	25mm Hailstone at the speed of 23m/s
Imp NOCT (A)	11.52
Imp STC (A)	14.07
Isc NOCT (A)	12.17
Isc STC (A)	15.07
Junction box	IP68
Max series fuse rating (A)	25
Max system voltage (V)	1500
Module code	LR7-72HTH-630M
Module efficiency (%)	23.3
Nominal operating cell temp (°C)	43-47
Operating temperature (°C)	-40 to 85
Output cable	4mm², +400/-200mm/±1400mm length can be customized
Package dimension (mm)	2382 x 1134 x 30
Package weight (kg)	28.5
Packaging	36pcs per pallet/144pcs per 20'GP/720pcs per 40'HC
Pmax NOCT (W)	470.8
Pmax STC (W)	630
Power tolerance (%)	0-3
Protection class	Class II
Rear static loading pa	2400
Temp coeff isc pct per (°C)	0.05
Temp coeff pmax pct per (°C)	-0.28
Temp coeff voc pct per (°C)	-0.23
Vmp NOCT (V)	40.87
Vmp STC (V)	44.78
Voc NOCT (V)	49.78
Voc STC (V)	53.02
Weight (kg)	28.5
