Felicity LPBF 48V battery low voltage ground 17.92 kWh

Name: Felicity LPBF 48V battery low voltage ground 17.92 kWh
Brand: Felicity
SKU: LPBF48350
Price: 1470 USD
Availability: BackOrder

350 Ah, about 17.5 kWh in a 162 kg floor case — the largest pack in the LPBF line.

TypeBatterieBatterieBasse tensionChimieLiFePO4Montageau solSystème51.2 V

Capacité

Prix$1,470

Caractéristiques clés

Battery class	Low voltage
Capacity (Ah)	350
Cell chemistry	LiFePO4
Energy (kWh)	17.92
Installation	ground
Nominal voltage (V)	51.2
System max energy (kWh)	105
Certification	UN38.3, CE-EMC, IEC 62619

Toutes les caractéristiques29

Battery class	Low voltage
Capacity (Ah)	250
Cell chemistry	LiFePO4
Energy (kWh)	12.8
Installation	ground
Nominal voltage (V)	51.2
System max energy (kWh)	75
Certification	UN38.3, CE-EMC, IEC 62619
Charging temperature range (°C)	0-55
Communication	CAN, RS485
Cut off voltage (V)	48
Cycle life	6000
Depth of discharge (%)	95
Dimension (mm)	615 x 350 x 955
Discharging temperature range (°C)	-20 to 60
Display	LED
Max charge discharge power 15s (kW)	10
Max charging voltage (V)	57.6
Max parallel units	6
Operating voltage (V)	48-57.6
Package dimension (mm)	718 x 450 x 1112
Package weight (kg)	177
Peak charge discharge current 15s (A)	200
Protection	Built-in Smart BMS, Breaker, Fuse
Protection degree	IP21
Recommend charge discharge current (A)	120
Recommend charge discharge power (kW)	6
Warranty (years)	5
Weight (kg)	154

Battery class	Low voltage
Capacity (Ah)	300
Cell chemistry	LiFePO4
Energy (kWh)	15.36
Installation	ground
Nominal voltage (V)	51.2
System max energy (kWh)	90
Certification	UN38.3
Charging temperature range (°C)	0-55
Communication	CAN, RS485
Cut off voltage (V)	48
Cycle life	6000
Depth of discharge (%)	95
Dimension (mm)	615 x 350 x 955
Discharging temperature range (°C)	-20 to 60
Display	LED
Max charge discharge power 15s (kW)	10
Max charging voltage (V)	57.6
Max parallel units	6
Operating voltage (V)	48-57.6
Package dimension (mm)	718 x 450 x 1112
Package weight (kg)	178.5
Peak charge discharge current 15s (A)	200
Protection	Built-in Smart BMS, Breaker, Fuse
Protection degree	IP21
Recommend charge discharge current (A)	120
Recommend charge discharge power (kW)	6
Warranty (years)	5
Weight (kg)	155.5

Battery class	Low voltage
Capacity (Ah)	350
Cell chemistry	LiFePO4
Energy (kWh)	17.92
Installation	ground
Nominal voltage (V)	51.2
System max energy (kWh)	105
Certification	UN38.3, CE-EMC, IEC 62619
Charging temperature range (°C)	0-55
Communication	CAN, RS485
Cut off voltage (V)	48
Cycle life	6000
Depth of discharge (%)	95
Dimension (mm)	622 x 350 x 955
Discharging temperature range (°C)	-20 to 60
Display	LCD, LED
Max charge discharge power 15s (kW)	10
Max charging voltage (V)	57.6
Max parallel units	6
Operating voltage (V)	48-57.6
Package dimension (mm)	718 x 450 x 1112
Package weight (kg)	185
Peak charge discharge current 15s (A)	200
Protection	Built-in Smart BMS, Breaker, Fuse
Protection degree	IP21
Recommend charge discharge current (A)	120
Recommend charge discharge power (kW)	6
Warranty (years)	5
Weight (kg)	162
